4G IP Camera Network Remote Control AI Dedicated Camera Module

4G AI dedicated IP camera module with SIM & max 64GB TF card slot, two-way audio, alarm, human detection & DV mode, compatible pinhole/wide-angle lens, custom casing for wireless remote surveillance.

Additional information

Details About Product

4G Camera Module Support SIM card and TF Card, Support Audio/Two-way Communication Function For Home Security Monitoring

This 4G IP camera features built-in 4G cellular connectivity for network remote monitoring, designed for portable wireless surveillance solutions. Equipped with a 1/2.7-inch CMOS sensor, it delivers 2MP (1920*1080) HD resolution with H.264 video encoding, and integrated 940nm IR LEDs to realize clear night vision monitoring, paired with over 100dB for balanced imaging under complex light conditions.

The 4G Camera module supports supprt SIM card and TF local storage, max support 64G TF card. It fully Support Audio/Two-way Communication Function, adopting G.711A/G.711U audio encoding for smooth real-time voice interaction.

Multiple intelligent functional: Alarm / Customized Investigation Area / Human-shaped Framing / Image Mirroring / DV Mode, plus remote shutdown and one-key reset operations.

This 4G camera module is compatible with multiple lens types including pinhole lens, button lens and wide-angle lens.  We also provide customized housing & casing service for 4G camera equipment to meet OEM demands.

Remote real-time viewing, video playback and footage download are available via dedicated mobile APPs for both Android and iOS systems, and it also supports WIFI all-in-one network connection for flexible deployment in wearable, portable, hidden surveillance and industrial monitoring scenarios. We can support customize clothes with 4G camera.



Specification:

Camera Type H.264 2MP IP Camera
CMOS Sensor 1/2.7 COMS
Resolution 1920*1080
Min. Illumination RGB 0.01Lux@F1.2
Interface FPC interface 24pin-0.5mm CIS/mipi(FPC-150MM)
FOVD FOVD 120°
Wide dynamic range >100db WDR
Vidoe Resolution 1920*1080P/1280*720P/640*480P
Frame rate 20-25FPS
Bitrate 32KB-20Mbps
WIFI All-in-one network connection
Remote Support
Human form detection Support
Night vision function Support
Video   Support for downloading via mobile phone
Audio Support Audio/Two-way Communication Function
Audio encoding G.711A/G.711U
Remote shutdown Support
Reset Support
Other functions Alarm / Customized Investigation Area / Human-shaped Framing / Image Mirroring / DV Mode
SD/TF Maximum support for 64GB
APP Android / Apple IOS
Power supply DC-5V(type-c)/3.7V Battery 2PIN-1.25
Power <5W
Work Environment (-20℃~+60℃,<90% RH)
