| Sensor | 1/9" CMOS Sensor |
|---|---|
| Resolution | 1280X720 |
| Out Diameter | 3.5mm |
| Interface | USB2.0 |
| FOVD | 100°, 120°, 140°, 70° |
This endoscopy camera module is used for CMOS OV9734 1/9″ sensor, with resolution 1280*720P, high frame rate 30FPS. It can not only be made into an outer diameter of 3.5mm endoscopic camera module , but also can be made into an outer diameter of 3.8MM 3.9mm endoscope camera module. This endoscopic camera module with LED and with Stainless Steel Sleeve, 4PCS LED . Camera module Length is 20±0.1mm. The standard FOV(Diagonal) of 3.5mm endoscopic camera module is Diagonal 100 degree, it also support 100°, 140°, 88°, 60°. The depth of field is 10-50mm. Diameter of cable is 1.5mm.
The endoscopic camera module can be supported output for USB, Intergated Type Camera moudule. Application for Industrial , Medical endoscopic; dental , ENT , Ear, Laryngoscopeand so on.
The biggest advantage is its relatively competitive price. The biggest disadvantage is its operating temperature of around 55℃, which completely fails to meet the requirements of medical endoscopy. If you require endoscope camera module that fully meets medical endoscopy requirements, please check the link : 3.9mm Endoscope Camera Module, 3.5mm Endoscope Camera Module, 3.3mm Endoscope Camera Module, and 2.0mm Endoscope Camera Module.
Specification :
| Item NO. | CBT-720P-E3.5V3.0 |
| Sensor | 1/9”CMOS |
| Out Diameter | Φ3.5MM With Stainless Steel Sleeve |
| Camera module Length | 20MM (Standard) ±0.1mm |
| Resolution | 1280X720@30 |
| FOV（Diagonal） | 87°, 100°, |
| Depth of field | 40MM-70MM(87°) 10MM-50MM(100°), 8-50MM(120°), 3-100MM (140°) |
| USB diameter | Φ3.8mm |
| USB cable length | 50CM (Standard Length) 1M (Standard Length), |
| LED QTY | 4PCS, LED current 10mA |
| Control LED brightness | YES |
| Storage temperature | -30 ℃–+85℃ |
| Operating Temperature | -0 ℃–+55℃ |
| High temperature resistance | +80℃ |
| Out put | USB, Type C |
| Support OS | UVC Standard, Windows/Linux/Andriod Systems |
